AMGO DX-12A

12,000 lb Alignment Double Scissor Lift

$12,375

Description

The AMGO DX-12A Double Scissors Lift is the ideal lift for easily and conveniently lifting all wheels off the runway for brake, tire, suspension and two or four-wheel alignment work. The DX-12A is made stronger, more versatile, and easier to use and can lift 12,000lbs.

Features

12,000lbs capacity for main scissor lift and 9,000lbs capacity for secondary scissor lift
Synchronization cylinders system equipped with hose burst valves
Safety stop device at the height of 11 3/4″, both control buttons are needed to lower the lift from 11 3/4″ to ground, with tone alarm for added safety
Skid proof diamond runways and optional adjustable turnplate pockets
Self-lubricating UHMW polyethylene sliders and bronze bushings

Specifications

Main Scissor Lifting Capacity	12,000 lbs (5,500 kg)
Lifting Time	63S
A1: Lifting Height	73 5/8″ (1870mm)
A2: Minimum Height	12″ (305mm)
B: Runway Length	196 1/2″ (4991mm)
C: Over Width	86 1/4″ (2190mm)
D: Runway Width	24 5/8″ (625mm)
E: Overall Length(Inc.Ramps)	257″ (6527mm)
F: Width Between Runway	37″ (940mm)
G: Min. Four Wheel Align	85 7/8″ (2180mm)
H: Max. Four Wheel Align	166 1/2″ (4230mm)
I: Max. Two Wheel Align	172 7/8″ (4390mm)
Secondary Scissor Lifting Capacity	9,000lbs (4000kg)
J: Secondary Scissor Lifting Height	16 1/2″ (420mm)
K: Secondary Scissor Length	63″~76 1/8″ (1600~1934mm)
Gross Weight	5,706 lbs (2,588 kg)
Motor	2.0HP 220V/60Hz Single Phase

Details on Freight

Your Auto Lift ships on a LTL common carrier freight company. It is taken to your location on a 48 foot semi truck. Please note the following before making your purchase:

You are responsilbe for unloading the lift from the truck. The truck driver does not unload it for you.
Lift Gate delivery service is not available for auto lifts.
You cannot unload an auto lift from the truck by hand. You must have machinery that can lift the full weight on your auto lift for unloading from the truck. Fork Lift, Bobcat, Tractor, Tow Truck, Back Hoe are all good options.
If you cannot unload from a truck, we can ship to our carrier's nearest freight terminal for you to pickup with a trailer or moving van.
You are responsible for calling the freight company to make a delivery appointment. We don't know your schedule so we can't do this for you.

When your lift ships, we will email you the carrier information and tracking number. Freight shipping is slower than small package shipping and can take 3-14 days depending on your location so please be patient.
