BendPak HD-973P - 9,000 and 7,000 Lb. Capacity / Tri-Level Parking Lift
by BendPak
SKU 5175238
Original price
$22,395.00
-
Original price
$22,395.00
Original price
$22,395.00
$22,395.00
-
$22,395.00
Current price
$22,395.00
The BendPak HD-973P is a four-post lift engineered for durable, everyday use in professional and home garage settings. It offers a 7,000-lb. lifting capacity, allowing it to accommodate a wide range of vehicles safely and securely. Drive-on ramps and a rugged steel frame make loading straightforward, while the runway design keeps access to the vehicle's underside convenient for service, storage, or display purposes. Built from heavy-gauge steel components, the HD-973P is designed to provide long-term reliability in demanding shop or storage environments.
| Style: | Multi-Level Parking Lift |
|---|---|
| Lifting Capacity* | 7,000 lbs. (3,175 kg) |
| *Max Capacity / Front Axle | 3,500 lbs. (1,588 kg) |
| *Max Capacity / Rear Axle | 3,500 lbs. (1,588 kg) |
| A - Overall Width | 110.5" (2,807 mm) |
| B - Overall Length | 241.75" (6,140 mm) |
| C - Height of Columns | 157.75" (4,007 mm) |
| D - Drive-thru Clearance | 86.5" (2,197 mm) |
| E - Maximum Rise | 139.5" (3,543 mm) |
| F - Maximum Lifting Height | 144" (3,667 mm) |
| G - Distance Between Columns | 100" (2,546 mm) |
| H - Runway Width | 19" (482 mm) |
| I - Width Between Runways | 35" (889 mm) or 41" (1,041 mm) |
| J - Runway Length | 180.25" (4,578 mm) |
| Min. Wheelbase @ rated Capacity 1 | 135" (3,429 mm) |
| Min. Wheelbase @ 75% Capacity 1 | 115" (2,921 mm) |
| Min. Wheelbase @ 50% Capacity 1 | 95" (2,413 mm) |
| Min. Wheelbase @ 25% Capacity 1 | 80" (2,032 mm) |
| Locking Positions | 31 |
| Locking Spacing | Every 4" (102 mm) |
| Lifting Time to Max. Rise | 90 seconds |
| Motor | 220 VAC / 60 Hz / 1 Ph |
| Lifting Capacity* | 9,000 lbs. (4,082 kg) |
| *Max Capacity / Front Axle | 4,500 lbs. (2,041 kg) |
| *Max Capacity / Rear Axle | 4,500 lbs. (2,041 kg) |
| A - Overall Width | 110.5" (2,807 mm) |
| B - Overall Length | 241.75" (6,1 40 mm) |
| C - Height of Columns | 157.75" (4,007 mm) |
| D - Drive-thru Clearance | 86.5" (2,197 mm) |
| E - Maximum Rise | 70" (1,783 mm) |
| F - Maximum Lifting Height | 72.25" (1,835 mm) |
| G - Distance Between Columns | 100" (2,546 mm) |
| H - Runway Width | 19" (482 mm) |
| I - Width Between Runways | 35" (889 mm) or 41" (1041 mm) |
| J - Runway Length | 165.5" (4,204 mm) |
| Min. Wheelbase @ rated Capacity 1 | 125" (3,175 mm) |
| Min. Wheelbase @ 75% Capacity 1 | 105" (2,667 mm) |
| Min. Wheelbase @ 50% Capacity 1 | 85" (2,159 mm) |
| Min. Wheelbase @ 25% Capacity 1 | 70" (1,778 mm) |
| Locking Positions | 13 |
| Locking Spacing | Every 4" (102 mm) |
| Lifting Time to Max. Rise | 50 seconds |
| Motor | 220 VAC / 60 Hz / 1 Ph |
| Shipping Weight: | 5,296-lbs (2,402 kgs) |
| Shipping Weight: | 5,296-lbs (2,402 kgs) |
