BendPak 16AP-192 Super-Duty Two Post Car Lift - 16,000-Lb Capacity - 192" Extended Height
With oversize dimensions and capabilities that go well beyond those typically found on traditional two post lifts, the 16AP-192 lifts more, lifts higher, reaches farther, and delivers more vehicle-supporting stability than ever before. With fewer moving parts, it's less susceptible to wear and tear, easier to maintain and less expensive to operate.
From accommodating large commercial trucks safely and lifting long awkward vehicles effortlessly, our Super-Duty AP Series handles heavy fleet tasks comfortably. Graciously spaced columns make for easier entry and exit, and ruggedly built far reaching arms increase lifting point coverage delivering greater stability.
Rugged Enough to Stand Up to Anything
Every Super-Duty AP Series lift delivers no-compromise construction, durability, the highest consumer confidence and safety rating, longest warranty, lowest cost of ownership and superior ergonomics.
High-Strength Multi-Face Columns
Our revolutionary multi-face metal columns redefine strength and durability, especially under biaxial loading conditions, providing unparalleled stability and resilience even in the most demanding environments.
Specifications
| Max. Lifting Capacity | 16,000 lbs. / 7,257 kg |
| A ā Max. Rise | 75.75 in. / 1,922 mm |
| B ā Lifting Height w/ Pad Down | 78.50 in. / 1,992.3 mm |
| C ā Max. Lifting Height w/ Pad Up | 82.5 in. / 2,095 mm |
| D ā Min. Height w/ Pad | 7.75 in. / 196.85 mm |
| E ā Overall Height | 193 in. (4,904 mm) |
| F ā Overall Width | 156 in. / 3,959 mm |
| G ā Width, Outside Posts | 143 in. / 3,238 mm |
| H ā Width, Inside Posts | 120 in. / 3,047 mm |
| I ā Width, Drive-Thru | 103 in. / 2,616 mm |
| J ā Floor to Top Switch | 186.50 in. (4,738.5 mm) |
| K ā Front Arm Reach | 36 in. to 65 in. (931 mm to 1,651 mm) |
| L ā Rear Arm Reach | 36 in. to 65 in. (931 mm to 1,651 mm) |
| Max. Load per Lift Arm | 4,000 lbs. / 1,814 kg |
| Pad Adapters Total Height | 7.50 in. / 188 mm |
| Time to Full Rise | ā45 seconds |
| Motor | 220 VAC, 60 Hz, 1 Phase |
| Sound | <70 dB |
