8000TLX Portable Truck Lift
by BendPak
SKU
Original price
$2,150.00
-
Original price
$2,175.00
Original price
$2,150.00
$2,150.00
-
$2,175.00
Current price
$2,150.00
8,000-lbs. Lifting Capacity / Extended Length / Portable Car Lift
The 8000TLX is QuickJack's most powerful extended-length portable truck lift, built to handle up to 8,000 lbs. Its 76-inch frame and 66-inch lift point reach make it ideal for long-wheelbase trucks, SUVs, and large sedans. Despite its size, it still fits under most sports cars with ease, reaching max rise in about 30 seconds and folding down to a low 3.5-inch collapsed height.
| 8000TLX Portable Truck Lift | |
|---|---|
| Lifting Capacity | 8,000 lbs. (3,629 kg) |
| A - Lowered Height (with 2" block) | 3.5" (89 mm) |
| B - Lifting Height (with 2" block) | 21" (521 mm) |
| C - Lifting Height (with 3" block) | 22" (546 mm) |
| D - Max. Lift Height | 24" (616 mm) |
| E - Lift Height (with adapters) | 24" (597 mm) |
| F - Lift Height (with adapters + pin) | 26.75" (673 mm) |
| G - Max. Lift Point Spread | 66" (1,676 mm) |
| H - Min. Lift Point Spread | 43" (1,092 mm) |
| I - Frame Width (each) | 11" (278 mm) |
| J - Frame Length (each) | 76" (1,930 mm) |
| Frame Weight (each) | 81.5 lbs. (37 kg) |
| Time to Full Rise | 30 seconds |
| Power Unit Weight | 15 lbs. (7 kg) |
| Shipping Dimensions (each frame) | 79.5" (L) x 15.25" (W) x 5" (H) (2,015 mm x 385 mm x 129 mm) |
| Shipping Weight | 250 lbs. (113 kg) |
