Model: 4032-6 / Three-Level 6-Car Storage Lift / 9,000 lb. Capacity Each Deck / 168" H X 212.4" W X 196.85" L / Ships Free
Authorized Dealer
We are an authorized dealer for all OLYMPIC branded products.
Why Choose Olympic?
When you buy an Olympic lift, you can expect a significant boost in performance and life expectancy. No one surpasses Olympic in quality, safety, or value, which means you can expect your Olympic Lift to be the last lift you ever buy. Internationally certified and tested to perform flawlessly at 150% of rated capacity
Model: 4032-6. Designed for high-capacity, three-level vehicle storage with U-Platform and L-Platform configuration. Features independent platform operation, and electric button controls.
Lifting Capacity (U-Platform): 9,000 lbs. | Lifting Capacity (L-Platform): 9,000 lbs.
Overall Height: 168″| Overall Width: 212.4″ | Overall Length: 196.85″
Specifications
| Product | Three-Level 6-Car Storage Lift |
|---|---|
| Model | 4032-6 |
| Lifting Capacity (U-Platform) | 9,000 lbs |
| Lifting Capacity (L-Platform) | 9,000 lbs |
| Height of Columns | 168″ |
| Upper Platform Max Rise | 147.44″ |
| Lower Platform Max Rise | 70.87″ |
| Clearance Between Platforms | 70.87″ |
| Column-to-Column Distance | 196.85″ |
| Drive-Thru Clearance | 171.57″ |
| Overall Width | 212.4″ |
| Overall Length | 251.46″ |
| Runway Length | 188″ |
| Park Width | 74.96″ |
| Runway Width | 212.4″ |
| Release Mode | Electric |
| Lock System | All-way anti-falling |
| Control | Button control |
| Surface Treatment | Powder coated |
| POWER UNIT | 220V / 5.5HP / 4.0 KW / 60Hz / 1 Ph. |
